1. Download
Use the download button at the top to save the .RBZ file to your computer.
SketchUp Extension · v1.0.0
CTS CNC Pattern Pro
Download Free Trial
Direct .RBZ download · No email or mobile required
3-day free trial
Built for your SketchUp workflow.
SU
SketchUpSketchUp 2021–2026
Install the plugin in SketchUp, click Try Free Trial, and enter your email and mobile number. Your 3-day trial starts at activation.
About this plugin
What you can do
**CTS_CNC_Pattern_Pro_V1.0.0** by CAD Tools Studio brings CAD import, image tracing, seamless pattern fills, and parametric design into one compact SketchUp plugin. Create decorative panels, jali screens, partitions, and custom patterns from DWG/DXF drawings, images, or geometric presets. Preview your design with clear red-and-green region selection, choose which areas to keep or remove, and generate 2D surfaces or extruded 3D geometry. Adjust dimensions, thickness, spacing, and repetitions with live previews. Image tracing offers **Normal** and **Complex** quality modes, smooth curve fitting, and a **Close Mini Gaps** option. Use **Edit Selected CNC** to modify previously created designs. The resizable interface rearranges its controls to leave more of your SketchUp workspace visible.
Get started
Install in 3 simple steps
2. Install
In SketchUp, open Extension Manager → Install Extension and select the downloaded .RBZ file.
3. Activate trial
Click Try Free Trial inside SketchUp and enter your email and mobile. Purchase a licence after the trial to continue.
Full version
Keep building after your trial
₹999.00
One-time purchaseCNC100 Save ₹100 at checkoutCompatible Software
Works with SketchUp
CTS CNC Pattern Pro supports professional SketchUp workflows on compatible Windows and macOS systems.
SU2021–2026
SketchUp
Windows & macOS
Licence & Updates
Buy Once. Use with Confidence.
One-time PurchaseNo recurring subscription fees.
Secure UpdatesUpdates for the purchased product version.
Support IncludedCustomer support when you need help.
Get CTS CNC Pattern Pro Today
Download directly and start your next SketchUp project.
₹999.00One-time purchase
Trial installers download directly without registration. Activate the 3-day trial from SketchUp using your email and mobile number. Secure payment is powered by PayU; paid access unlocks after server-side payment verification. One active computer is permitted per licence. Same-computer reinstall is allowed when the Machine ID matches; a different computer requires an administrator-approved reset. This independent extension is not affiliated with, endorsed by or sponsored by Trimble Inc. or SketchUp.
